Rossella Plus Forno Evo 9,1kW

Features: Hearth in cast-iron with postcombustion • External facing in natural stone or majolica • Doors and top-plate in enameled cast-iron • Internal ash drawer • Enameled oven 37 l • Ceramic glass resistant up to 750°C

ROSSELLA PLUS FORNO EVO

9,1kW/260m³

Useful thermal power/Heated volume

Features: Hearth in cast-iron. Postcombustion. External facing in natural stone or majolica. Doors and top-plate in enameled cast-iron. Internal ash drawer. Enameled oven 37lt. Ceramic glass resistant up to 750°C. Extractable wood drawer.

Technical Data

Dimensions (WxHxD)	559x1359x536mm
Weight	195kg\|PT219kg
Door opening (WxH)	355x245mm
Hearth dimensions (WxHxD)	379x370x327mm
Oven dimensions (WxHxD)	330x300x370mm
Heatable	260m³
Fumes outlet	130mm
Draught	12Pa
Air inlet	120mm (optional)
Hearth material	Cast-Iron
Total thermal power	10,6kW
Useful thermal power	9,1kW
Efficiency	86,0%
Consumption	2,4kg/h
