VYDA

18,7kW/485m3

Useful Thermal Power/Heated Volume

Hermetic pellet thermo-stove for passive houses or low energy houses. Pellet boiler stove that supplies radiators and floor radiant heating panels throughout the home. Available with ceramic top and inserts in three colour options: bordeaux, white and black. It produces hot air for heating the installation room as well.

• Leonardo system
• Cast iron and steel firebox
• Rear smoke outlet O 8 cm
• Synoptic panel
• Daily / weekly programming
• Cpump and pressure relief valve

Technical Data

Dimensions (WxDxH) 625x615x1215mm
Weight 260kg
Heatable 485m3
Fumes outlet 80mm
Draught 1-10Pa
Air Inlet 60mm
Hydraulic Connections 3/4" F
Boiler Content 20lt
Useful thermal power 18,7kW
Power given to water 16,3kW
Efficiency >93,3%
Consumption 1,1-4,2kg/h
Pellet tank ~37kg

 OPTIONAL
• Kit Wi-Fi
• GSM, allows for switching the stove on/off via mobile phone
