INSERTO 70 CRYSTAL - VENTILATO
9,0kW/258m3
Useful thermal power/Heatable Volume
LA NORDICA-EXTRAFLAME Inserts: reliable. Practical, silent and ecological, they enable to heat wide areas in very short time.
Features:
- Extractable ash drawer
- Hearth in cast-iron and Nordiker
- Ceramic glass heat-resistant 750°C
- Standard tangential fans
- Adjustable primary and secondary air, preset tertiary air
- Post combustion system
- Possibility to change by yourself the door opening direction from right to left
Technical Data
| Dimensions (WxHxD) | 700x555x500mm |
| Weight | 124kg |
| Door Opening (WxH) | 540x245mm |
| Hearth Dimensions (WxHxD) | 500x320x360mm |
| Heatable | 258m3 |
| Fumes Outlet | 160mm |
| Draught | 12Pa |
| Air Inlet | 120mm |
| Hearth material(s) | Cast Iron-Nordiker |
| Total Thermal Power | 11,3kW |
| Useful Thermal Power | 9,0kW |
| Efficiency | 78,2% |
| Consumption | 2,7kg/h |
