Inserto 50 Verticale Crystal BII - Ventilato 8,3 kW

Wood burning ventilated insert for fireplaces. Extractable ash drawer. Hearth in cast-iron and Nordiker. Ceramic glass heat-resistant 750°C. Door in cast iron. Standard tangential fans. Adjustable primary and secondary air, preset tertiary air with post combustion system.

INSERTO 50 VERTICALE CRYSTAL BII - VENTILATO

8,3kW/237m³

Useful thermal power/Heated Volume

LA NORDICA-EXTRAFLAME Inserts: reliable. Practical, silent and ecological, they enable to heat wide areas in very short time.

Features:

Extractable ash drawer
Hearth in cast-iron and Nordiker
Ceramic glass heat-resistant 750°C
Door in cast iron
Standard tangential fans
Adjustable primary and secondary air, preset tertiary air
Post combustion system
Possibility to change by yourself the door opening direction from right to left

Technical Data

Dimensions (WxHxD)	500x800x500mm
Weight	115kg
Door Opening (WxH)	335X460mm
Hearth Dimensions (WxHxD)	300x500x360mm
Heatable	237m³
Fumes Outlet	150mm
Draught	12Pa
Hearth materials	Cast Iron+Nordiker
Total Thermal Power	10,2kW
Useful Thermal Power	8,3kW
Efficiency	81,0%
Consumption	2,3kg/h
