VERONA XXL MAIOLICA

7,0kW/200m3

Useful Thermal Power/Heated Volume

Wood burning cooker with option of fitting between furniture.

Features:

  • External facing in majolica
  • Extractable ash drawer
  • Enameled steel facade
  • Internal facing of the hearth in cast iron and Nordiker
  • Top cooking plate and rings in polished cast-iron
  • Cast iron fire door, oven door in enamelled steel
  • Reversible doors
  • Stainless steel frame
  • Fire door with internal combustion air path for glass cleaning and efficiency
  • Adjustable primary and secondary air for a better combustion control
  • Post combustion system (low emissions)
  • Oven with excess steam valve
  • Porcelain enamelled steel oven 68 l with light
  • Chromed oven rack with pull out guides
  • Double glass oven door and stainless steel gaskets
  • External air intake
  • Ceramic glass
  • Top thickness 3 cm
  • Wide fire vision
  • Frontal handrail
  • Fire door in cast iron with double glass
  • Possibility to use 50 cm logs (subject to compliance with the hourly fuel consumption data provided for the model)
  • Option of fitting between furniture cabinets
  • Upper central, rear, right side or left side smokes outlet.

Technical Characteristics

Dimensions (WxHxD) 800x910x600mm
Weight 220kg
Heatable 200m3
Fumes outlet 150mm
Draught 10Pa
Air inlet 100mm
Hearth material Cast-Iron+Nordiker
Total thermal power 8,2kW
Useful thermal power 7,0kW
Efficiency 85,1%
Consumption 1,9kg/h
